Kub Kub Pob Valve

Los ntawm peb lub hauv paus tsim khoom hauv Wenzhou, Tuam Tshoj, Huadu Valve Group tsim tshwj xeeb li qub txhais tau tias xav tau kev lag luam kev lag luam. Peb lub tuam txhab High Temperature Ball Valve siv cov khoom siv hluav taws xob kub-resistant alloy lub cev ua ke nrog cov ntaub ntawv kub-resistant sealing los tiv thaiv cov kub kub kub thiab kub kub nruab nrab. Optimized internal qauv zoo tiv thaiv kev foob tsis ua hauj lwm los ntawm thermal expansion, zoo tagnrho rau petrochemical, fais fab nroj tsuag thiab high-temperature cua sov pipelines.Peb muaj ISO thiab API daim ntawv pov thawj raws li zoo raws li mob siab rau high-temperature test benches thiab tag nrho nyob rau hauv-tsev soj ntsuam. Yooj yim OEM thiab ODM customization yog muaj, nrog rau yam tsawg kawg nkaus txiav txim kom muaj nuj nqis tham txog ib qho kev txiav txim. Cov valves kub kub no muag thoob ntiaj teb thiab tau txais kev ntseeg siab los ntawm ntau tus neeg siv khoom txawv teb chaws.

Xa lus nug

Product Description

Qhov ntsuas kub li cas ua cov pob valve muaj?

Ordinary cov pa roj carbon steel pob li qub uas tsis muaj kev hloov kho qhov kub thiab txias feem ntau ua haujlwm ruaj ntseg hauv -20 ℃ txog 180 ℃. Thaum ua haujlwm kub siab tshaj 200 ℃, PTFE cov ntsaws ruaj ruaj yuav muag muag, deform thiab pib xau yooj yim, thiab cov cam khwb cia hlau zoo tib yam yuav maj mam ua rau lub sijhawm ntev kub. Peb li niaj zaus GB ntab pob li qub ua raws li qhov ntsuas kub no thiab tsuas yog tsim nyog rau chav dej kub, cov pa kub ib txwm thiab cov kua dej uas muaj cua sov uas tsis tshua muaj, uas tsis tuaj yeem sawv ntsug ntev mus rau qhov kub kub lossis cov roj kub. Nyob rau hauv sib piv, peb lub siab kub-kub pob li qub ua txhaum no tag nrho.

Dab tsi ua rau lub pob valve "siab kub"?

Lub pob valve tsim nyog raws li qhov kub thiab txias feem ntau los ntawm peb qhov kev hloov kho tshiab txawv ntawm cov qauv qauv. Ua ntej yog customized kub-resistant sealing qhov chaw es tsis txhob PTFE muab tub lim; peb txais yuav graphite, hlau-rau-hlau nyuaj foob los yog tshwj xeeb alloy sealing rings uas yuav tsis soften nyob rau hauv khaus kub. Qhov thib ob yog optimized lub cev qauv tsim, nrog tshwj xeeb expansion qhov sib txawv tshwj xeeb nyob rau hauv lub valve kab noj hniav kom offset hlau thermal expansion thiab tsis txhob daig pob los yog foob crush thaum kub kub. Qhov thib peb yog xaiv cov khoom siv hluav taws kub-resistant rau lub cev thiab sab hauv trim. Ua tsaug rau peb qhov kev txhim kho no, lub valve nyob twj ywm nruj thiab hloov tau txawm tias nyob rau hauv kev kub ntxhov, uas yog qhov sib txawv tseem ceeb cais nws los ntawm cov pob li qub.

Cov cwj pwm tseem ceeb

Yam khoom	Kub Kub Pob Valve	Cov khoom siv qia	A182 F304 / A182 F316 / 13Cr
Tsim qauv	API 6D / ASME B16.34	Khoom siv zaum	Stellite Hardfaced / PTFE / RPTFE
Lub ntsej muag rau ntsej muag Dimension	ASME B16.10	Hom Gasket	Kauv qhov txhab Gasket / RTJ Gasket / Graphite Gasket
Flange Txheem	ASME B16.5 / ASME B16.47	Hom kev ua haujlwm	Handwheel, Iav Ua Haujlwm, Fais Actuator, Pneumatic Actuator, Hydraulic Actuator
Qib Siab	Chav Kawm 150/300/600/900/1500	Xaus kev sib txuas	Flanged, Threaded, Welded (BW / SW)
Nominal Loj (NPS)	1/2 "~ 48"	Hom tsim	Floating Pob / Trunnion Pob, Bolted Bonnet
Khoom siv lub cev	A216 WCB	Qhov kub thiab txias	-29 ℃ ~ 425 ℃
Khoom siv Bonnet	A216 WCB	Siv tau nruab nrab	Dej, roj, roj, chav, General Industrial Fluid
Nplaum / Disc Material	A216 WCB + Hardfaced / A105 + Hardfaced / F304 / F316	Kev xeem Standard	API 598 / Hydrostatic Plhaub & Seat Test

Cov ntaub ntawv twg yog qhov zoo tshaj plaws rau lub cev valve?

Kev xaiv cov khoom yog nyob ntawm qhov kub thiab txias ua haujlwm. Rau kev ua haujlwm kub hauv qab 450 ℃, alloy steel zoo li WC6 / WC9 yog peb cov nqi tsim nyog tshaj plaws, siv dav hauv cov kav dej thiab cov roj kub kub hauv kev lag luam petrochemical thiab thermal zog. Yog hais tias ua hauj lwm tej yam kev mob ntaus mus txog 550 ℃ los yog nqa me ntsis corrosive high-temperature nruab nrab, F304 thiab F316 stainless hlau yog cov kev xaiv rau zoo dua kub thiab corrosion kuj. Rau ultra-siab kub tshaj 600 ℃ nyob rau hauv hnyav hnyav ua hauj lwm ib puag ncig, peb siv tshwj xeeb high-temperature chrome-moly alloy steel ntawm customized txiav txim. Ordinary WCB carbon steel siv rau ntawm lub pob li qub tsis pom zoo rau kev ua haujlwm kub kub.

Dab tsi yog kev lag luam uas yuav tsum tau kub-kub pob li qub tshaj plaws?

Cov li qub no tau siv ntau hauv cov chaw tsim hluav taws xob thermal, petrochemical refining, khib nyiab rov qab tshuab, boiler chav pipelines thiab asphalt xa cov kab. Cov kev ua haujlwm zoo li no ua rau muaj qhov kub thiab txias tsis tu ncua, cov roj kub kub thiab cov kua dej kub kub, qhov twg cov pa roj carbon steel pob li qub tsis tuaj yeem ua haujlwm ruaj khov mus ntev.

Cov qib siab dab tsi ua rau koj lub pob valve npog?

Peb cov khoom lag luam npog PN16 txog PN100 kom phim ntau yam kev kub ntxhov siab ua haujlwm kub. Qhov nruab nrab kub-kub feem ntau ua rau lub siab hloov pauv loj dua, yog li peb ua kom lub cev lub cev tuab thiab ntxiv dag zog rau sab hauv cov qauv piv nrog ib txwm-kub GB pob li qub txhawm rau txhim kho kev ua haujlwm siab ntawm tag nrho.

Hot Tags: High Temperature Pob Valve, Chaw tsim tshuaj paus, tsum, Hoobkas, Suav teb
